Air Hydraulic Foot Pump, 10000 PSI, 0.69 L Reservoir, 2 m Hose

Air Hydraulic Foot Pump, 10000 PSI, 0.69 L Reservoir, 2 m Hose

Product form
Item number: 11370262659399

10,000 PSI air hydraulic pump delivers fast, foot-controlled hydraulic power for lifting, pressing, bending, cutting, and assembly work in demanding... Read more

Currently unavailable

€304,99  €276,99

    Pay securely with

    • Apple Pay
    • Google Pay
    • Visa
    • Mastercard
    • American Express
    • Klarna
    • Free shipping
    • 30-day returns
    • Secure checkout

    Specifications

    Maximum output pressure10,000 PSI (689 bar)
    Input air pressure110–145 PSI
    Air flow rate340 L/min
    Hydraulic flow rate0.8 L/min (no load) / 0.16 L/min (load)
    Reservoir capacity0.69 L / 0.18 gal (factory-filled with #13 hydraulic oil)
    Air inletNPT 1/4 in (13.7 mm)
    Oil outletNPT 3/8 in (16.66 mm)
    Hose length2 m / 6.56 ft; reinforced rubber with 3 steel-wire layers; rated 125 MPa
    Dimensions7.91 x 6.50 x 5.71 in (455 x 165 x 145 mm)
    Net weight14.68 lb / 6.65 kg

    Description

    10,000 PSI air hydraulic pump delivers fast, foot-controlled hydraulic power for lifting, pressing, bending, cutting, and assembly work in demanding shops. Air-actuated treadle operation keeps your hands free while building pressure quickly and releasing on command. A factory-filled 0.69 L reservoir reduces setup time, and standard NPT ports make it easy to integrate with compatible hydraulic tools and systems. Built with a metal shell and integrated relief valve for dependable operation under load.

    Designed for precision industrial machinery and aerospace equipment maintenance, this compact air-over-hydraulic pump supports consistent pressure control for shop presses, hydraulic cylinders, cutters, and spreaders. The reinforced, steel-wire hose helps reduce leak risk and improves flexibility when working around fixtures or vehicles. A durable metal housing and internal relief valve add protection for hydraulic components during repeated cycles. If you need reliable 10,000 PSI output with simple foot operation and minimal setup, grab yours today and keep your workflow moving.

    Specifications
    • Delivers up to 10,000 PSI max output with 340 L/min airflow for heavy-duty hydraulic tasks
    • Includes a 0.69 L / 0.18 gal reservoir pre-filled with #13 hydraulic oil for quicker startup
    • Controls pressure via air-actuated treadle for hands-free operation and fast release
    • Connects to standard NPT 1/4 in air inlet and NPT 3/8 in high-pressure oil outlet
    • Handles reach and routing with a 2 m reinforced rubber hose rated up to 125 MPa
